Offshore Environmental Oils (OEO) Ltd is a dedicated supplier of ‘super environmental’ oil based hydraulic fluids to the Offshore Oil and Gas industry.

The aim of OEO is to provide environmentally acceptable alternatives to mineral oils across a wide plethora of applications including both topside and subsea hydraulic systems.

OEO has staff with many years experience in the Offshore hydraulics fluid market and can offer customers an excellent service and capability.

For Subsea Systems, our product range consists of :

  • CLEO (Closed Loop Environmental Oil) which is a super high temperature environmental oil based subsea control fluid capable of operation at 250C.
  • HDEO Range fluids are High Density, Environmental Oil based Subsea Actuator Fluids, designed for applications where a specific gravity greater than seawater is required.

For Topside Systems our product range is designed to replace mineral oils across a wide range of topside hydraulic systems and offers customers an OCNS Class E (UK) and Yellow 1 (Norwegian) Environmental profile.

Live Oil Prices :
  Crude Oil (WTI) :
  Crude Oil (Brent) :
Company Brochure >>


Content on this page requires a newer version of Adobe Flash Player.

Get Adobe Flash player

Environmental perspective : Our products are aimed mainly at the Norwegian, UK, Australian and Alaskan markets due to their extremely high environmental pedigree but are also suitable for use in many other areas around the world.


Technical perspective : We are able to offer bespoke solutions to equipment manufactures and operators requiring technology for specific applications on a global basis and this is an area in which we excel.




Product Range
Fluid Selector
Reset
Further Detail ⇓
To assist in choosing the correct product for your application, please select the relevant parameters below. The appropriate products will be shown to the Right >>
Product Application :
Temperature Range :


-40°C 250°C

Viscosity Range :


0     250
Environmental Region :
N/A
Yellow
Green



Specific Gravity :


0.8 1.2

Minimum Cleanliness :


Nas 6 Nas 11

Minimum Bulk Modulus :


Low(1) High(3)

Low Foaming :


Low High


Water Soluble
Float

Yes
No

CLEO
Key Features
Physical Data
Downloads
  • Upper Temperature limit 250°C/ 488°F
  • Excellent Lubrication & Anti-wear
  • Excellent Anti-Corrosion Properties
  • Outstanding Environmental Properties
  • Yellow Y1/OCNS Class E for discharge
  • Suitable for Closed/Return Systems
  • Fully compatible with Brayco Fluids
  • Extensive Material & Equipment Qualification
    Appearance Colourless/Yellow
    Pour Point(°C) <-40
    Upper Temperature (°C) 250
    Specific Gravity 0.918
    Viscosity @ 0 °C 35.7
    Viscosity @20 °C 14.6
    Viscosity @40 °C 8.45
* These properties are typical for the product but do not constitute a specification
HDEO
Key Features
Physical Data
Downloads
  • Reduced Viscosity and Increased S.G.
  • Excellent Environmental Profile
  • Excellent Health & Safety Properties
  • Upgraded Lubrication & Anti-wear
  • Upgraded Anti-Corrosion Package
  • Excellent Microbiological Properties
  • Outstanding Long Term Stability
  • Extensive Material Compatibility Data
    Appearance Pale Yellow
    Pour Point(°C) <-25
    Upper Temperature (°C) 200
    Specific Gravity 1.080
    Viscosity @ 0 °C 1137 cSt
    Viscosity @20 °C 305 cSt
    Viscosity @40 °C 101 cSt
* These properties are typical for the product but do not constitute a specification
HDEO EP
Key Features
Physical Data
Downloads
  • Outstanding Environmental Profile
  • Yellow Y1/OCNS Class E for discharge
  • Excellent Health & Safety Properties
  • Excellent Lubrication & Anti-wear
  • Excellent Anti-Corrosion Properties
  • Excellent Microbiological Properties
  • Outstanding long term stability
  • Extensive material compatibility data
    Appearance Colourless/Yellow
    Pour Point(°C) <-10
    Upper Temperature (°C) 200
    Specific Gravity 1.063
    Viscosity @ 0 °C 2815 cSt
    Viscosity @20 °C 633 cSt
    Viscosity @40 °C 183 cSt
* These properties are typical for the product but do not constitute a specification
EO08
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.915
    Viscosity @40 °C 8
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO12
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.925
    Viscosity @40 °C 12
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO18
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.937
    Viscosity @40 °C 18
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO32
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.952
    Viscosity @40 °C 32
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO46
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.962
    Viscosity @40 °C 46
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO68
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.976
    Viscosity @40 °C 68
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO100
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.984
    Viscosity @40 °C 100
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO150
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.994
    Viscosity @40 °C 150
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EO220
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Excellent Stability and Microbiological Protection
  • Electrical Insulation Grades Available
  • Available in a number of viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.998
    Viscosity @40 °C 220
    Water Solubility Insoluble
    Oil Solubility Miscible
* These properties are typical for the product but do not constitute a specification
EΩ-08
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • Offers High Di-electric Strength
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Suitable for many electrical insulation applications
  • Available in 3 viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.915
    Viscosity @40 °C 8
    Di-electric Strength (keV) >55
    PCA/PCB Content None
    Water Content (ppm) <200
    Furfural (mg/kg) <0.1
    Neutralisation Value(mg KOH g) <0.2
    These properties are typical for the product but do not constitute a specification
EΩ-32
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • Offers High Di-electric Strength
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Suitable for many electrical insulation applications
  • Available in 3 viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.952
    Viscosity @40 °C 32
    Di-electric Strength (keV) >55
    PCA/PCB Content None
    Water Content (ppm) <200
    Furfural (mg/kg) <0.1
    Neutralisation Value(mg KOH g) <0.2
    These properties are typical for the product but do not constitute a specification
EΩ-220
Key Features
Physical Data
Downloads
  • Environmental alternative to ISO Hydraulic Oils
  • Offers High Di-electric Strength
  • OCNS Class E under UK Legislation
  • Yellow 1 under Norwegian Legislation
  • Outstanding Environmental Properties
  • Outstanding Lubricity and Anti-wear characteristics
  • Suitable for many electrical insulation applications
  • Available in 3 viscosity grades
    Appearance Colourless/Yellow
    Pour Point(°C) <-25
    Specific Gravity 0.998
    Viscosity @40 °C 220
    Di-electric Strength (keV) >55
    PCA/PCB Content None
    Water Content (ppm) <200
    Furfural (mg/kg) <0.1
    Neutralisation Value(mg KOH g) <0.2
    These properties are typical for the product but do not constitute a specification







Topside Environmental Oils
For Topside systems the main product portfolio is designed around our EO (Environmental Oil) range comprising different ISO viscosity grades such as EO08, EO12, EO18, EO32, EO68, EO100, EO150 and EO220.

This product range is designed to replace mineral oils across a wide range of topside hydraulic systems and offers customers an OCNS Class E (UK) and Yellow 1 (Norwegian) Environmental profile.
Subsea  Control Fluids
CLEO is an Environmental Oil based subsea production control fluid capable of operation between -45°C and +250°C and is designed for super high temperature/high pressure wells and closed loop systems utilising a return line to platform.

HDEO Range fluids are High Density, Environmental Oil based Subsea Actuator Fluids, designed for applications where a specific gravity greater than seawater is required.
CLEO Environmental Oil
CLEO is a High Temperature Environmental Oil based Subsea Control Fluid. It was developed to bridge the technology gap between water based fluids and the extreme HP/HT developments of the future, by providing a very stable high temperature fluid capable of maintaining temperatures in excess of 250°C for a project lifetime.

In addition, with the potential future requirements for closed loop systems in some sectors this environmental oil is not only acceptable for direct discharge to sea, but is designed to offer all the properties of traditional oil based fluids in closed loop systems.





Copyright ©2013 -2014 Offshore Environmental Oils. All rights reserved | Contact Us | +44(0) 8452 967751 | Walter Leigh Way, Moss Industrial Estate, Leigh, Lancashire, WN7 3PT
